2. DM13 hardware configuration, dimensions, output power parameters

DM13 adopts independent DAC 43198*2+SGM8262*2 HIFI professional architecture audio configuration. Its configuration and sound quality are better than the CD players within 300USD.

What is the CD mechanism and Laser pickup of DM13?

CD mechanisms and Laser pickups are necessary for a good CD player so no manufacturer will spend less on them.

DM13 uses the best and most stable CD mechanism for portable machines. The manufacturer is the best and biggest factory to make portable CD mechanisms in China.

The three core components for the Laser pickup part of the CD mechanism used by DM13 are all the current TOP1.

As for individual components related to disc reading, we are also using the best in the market now.

Dimensions of DM13

Anout 137 * 144 * 27mm (Footpads are not included)

It is slightly larger than the K11 and the most portable CD player in the market now.

Output Power

3.5mm headphone output:

L+R≥180mW+180mW (32Ω, THD+N＜1%)

4.4mm balanced headphone output:

L+R≥660mW+660mW (32Ω, THD+N＜1%)

It has the highest outpuy power in portable CD products. 180mW@32 ohms single-ended, 660mW@32 ohms balanced.

Battery capacity

3750mAh 3.8V high voltage lithium battery

Battery life

Over 10 hours @40mV output

How to check the battery level of the DM13?

When powering on, short press the first button (power button). In the display, BAT5 means full power, BAT4 means 80~90% power, BAT3 means 60~80% power, BAT2 means 40~60% power, BAT1 means 20~40% power, and BAT0 means low power (DM13 needs to be charged).

Why use flip cover design?

The flip cover reads the disk better and has a ceremonial feeling. Besides, it is not easy to scratch the disk.

ESP

Electronic Shock Protection (ESP) is a handy feature that ensures that your MP3-CD player will play music without skipping a beat even if it is shaken or bumped during movement. Devices with ESP have an intelligent electronic buffer that can store different digital music formats such as MP3 and WMA. The buffer automatically adjusts its contents and the laser pickup speed to ensure that you enjoy the music smoothly.The DM13 has an ESP function that users can choose to turn on or off by themselves.Audiophiles who care about sound quality are recommended to turn ESP off; ESP is only suitable for moving scenes

ESP compression time after ESP pre-reading: normal CD disks ESP will have 60 seconds pre-reading, MP3 format disks will have 120 seconds pre-reading.

Does DM13 support gapless playback?

Yes.

DM13 Bluetooth version

5.2

Does DM13 support USB audio output?

DM13 does not support USB audio output. Its digital output only supports coaxial and optical output.

Which play modes are supported by the DM13?

DM13 can support repeat all, single repeat, repeat randomly, play stop until playing the last song.
